ETS ONLY

Includes

ETS ONLY

Compatibility

1100MX
770MX
1100M
770M
PCNC 1100
PCNC 770
PCNC 440

Specs:

Repeat Accuracy 0.002mm
Protection Level IP67
Working Temperature 0~80℃
Top plate diameter 20mm
Lifespan 3 million times

Requirements

PathPilot controller

An Electronic Tool Setter (ETS) is a device used in CNC (Computer Numerical Control) machining to precisely measure and set the position, length, and diameter of cutting tools. It ensures that the tools are accurately aligned and positioned in relation to the workpiece before machining begins, improving efficiency, precision, and quality control.

Key Features and Functions of an ETS:

1. Tool Length. ETS measures the exact length of the tool, accounting for any wear or inaccuracies.

2. Automatic Tool Offset Adjustment: It automatically updates the CNC machine’s controller with the correct offsets, ensuring that the cutting tool’s position is accurately referenced.

3. Error Reduction: By eliminating manual measurement errors, ETS increases the reliability and accuracy of the machining process.

Benefits of Using an ETS:

• Increased Efficiency: Reduces setup time by automating tool measurement.

• Higher Precision: Enhances machining accuracy by precisely setting the tool.

• Reduced Tool Wear: Detects worn tools early, preventing potential issues with the final product.

ETS devices are commonly used in high-precision manufacturing environments, such as automotive, aerospace, and medical device production, where tight tolerances are crucial.
